Product Description:

This 60V 20Ah lithium battery is equipped with advanced LiFePO4 technology. It offers reliable energy solutions for various applications, ensuring long-lasting performance and safety.

Technical Parameters:

Nominal Voltage	60V
Nominal Capacity	20Ah
Energy	1200Wh
Charge/discharge Cut-off Voltage	46.75V
Max Charge Current	20A
Max Discharge Current	20A
Cycle Life	≥ 5000 Cycles (@80% Depth of Discharge)
Charging Temperature	0°C ~ 60°C
Discharging Temperature	-20°C ~ 65°C
Casing material	Metal
Terminals type	M8
IP Rate	IP65
BMS	Overcharge, Over-discharge, Overcurrent, Short Circuit, High Temp
Weight	Approx. 19kg
Dimensions	L330mm × W237mm × H172mm (customizable)



Main Features:

High Energy Capacity: With a rated capacity of 20Ah and an energy output of 1,216Wh, this battery is ideal for efficiently powering a wide range of devices.
Durable and Weatherproof: Featuring an IP65 rating, this battery is dustproof and waterproof, making it suitable for outdoor and industrial applications.
Long Lifespan: Capable of exceeding 3,000 cycles at 80% Depth of Discharge (DOD), this battery minimizes the need for frequent replacements, delivering outstanding long-term value.
Smart Battery Management System (BMS): Equipped with an intelligent BMS that prevents overcharging, overheating, and short circuits, ensuring safe operation.
Compact Design: Weighing just 10 kg, this lightweight battery is easy to install and integrate into various systems.

Applications:

Automated Guided Vehicles (AGVs)
Electric Rickshaws and Electric Tricycles
Floor Cleaning Machines
Renewable Energy Storage Systems
Marine Applications such as Yachts and Fishing Boats



Advantages:

Maximum charging voltage: 69.3V

Discharge cutoff voltage: 46.75V

This battery is optimized for diverse operational requirements. It operates reliably from -20°C to 55°C, ensuring adaptability across varying environments. Its lightweight design facilitates easy installation while guaranteeing efficient, all-day performance for your devices. Additionally, it supports fast charging capabilities, minimizing downtime between uses.
