Type	13S lithium battery protection board
Battery Type	Li-ion
Compatible Interface	RS485
Over charge detection voltage(Cell)	4.250V±0.050V  Adjustable
Over Discharge Detection Voltage(Cell)	2.500V±0.050V  Adjustable
Over Current Discharge	80A±5A Adjustable
Over Current Charge	50A±5A  Adjustable
Discharging Temperature	-20℃~65℃  Adjustable
Charge Temperature	-0℃~50℃  Adjustable
Max.Discharge Current	60A
Dimension	156*70*12 mm
Sample	Available

The BAKTH-013S060A-0026-01 is a high-performance 13-series (13S) Battery Management System (BMS) engineered for robust 48V lithium-ion and lithium-polymer battery packs. Designed to deliver an exceptional maximum continuous discharge current of 60A, this board is built for demanding applications where high power, absolute safety, and long-term reliability are critical.

Integrating comprehensive protection circuitry with precise cell balancing, this BMS ensures optimal performance and maximizes the lifespan of your high-voltage battery pack, making it the ideal cornerstone for commercial, industrial, and high-power mobility solutions.

---

Key Features & Benefits:

• • Exceptional High-Current Handling: Capable of supporting a massive 60A continuous discharge current, this BMS is perfect for powering high-demand systems such as electric vehicles, powerful industrial tools, and large energy storage systems without performance loss.

  • Comprehensive Protection Suite: Provides multi-layered safety to safeguard your valuable battery investment and end-users:

    • Over-Current Discharge Protection: Automatically interrupts the circuit during excessive current draw, preventing damage.

    • Over-Charge Protection: Prevents any cell from exceeding its maximum voltage threshold during charging.

    • Over-Discharge Protection: Disconnects the load to avoid deep discharge, which can cause irreversible cell damage.

    • Short-Circuit Protection: Offers instantaneous shutdown in case of a short circuit, ensuring system safety.

  • Precision Passive Balancing: Features an integrated balancing circuit that actively equalizes the voltage across all thirteen cells during the charging process. This is crucial for maximizing the total energy capacity of the pack and ensuring uniform cell aging, thereby extending the overall service life.

  • Optimized for 13S Configuration: Expertly calibrated for 13-series battery chains, managing a nominal voltage of 48V and a full charge voltage of 54.6V.

  • Robust Construction for Demanding Environments: Built with premium-grade components, including high-current MOSFETs and a durable PCB, designed to ensure stable operation and dissipate heat effectively under continuous high-load conditions.
