BAKTH-0040150037-01 4S 10A PCM
| Description | |
| Model NO. | BAKTH-0040150037-01 |
| Compliant certification standards | IEC62133/UL2054 |
| Type of Protective Board | 4-series SMB intelligent battery protection board |
| Compatibleinterface | SMBUS |
| Electrical Performance | |
| Battery Type | Li-ion |
| Over charge detection voltage(Cell) | 4.250V±0.025V |
| Over Discharge Detection Voltage(Cell) | 2.500V±0.025V |
| Over Current Discharge | 15.0A±0.2A |
| Over Current Charge | 15.0A±0.2A |
| Discharging Temperature | -20~65℃ Adjustable |
| Charge Temperature | -5~50℃ Adjustable |
| Max.Discharge Current | 10A |
| Dimension | |
| Length | 65± 0.3mm |
| Width | 32± 0.3mm |
| Height | 3.79± 0.3mm |
| Description | |
| Model NO. | BAKTH-0040150037-01 |
| Compliant certification standards | IEC62133/UL2054 |
| Type of Protective Board | 4-series SMB intelligent battery protection board |
| Compatibleinterface | SMBUS |
| Electrical Performance | |
| Battery Type | Li-ion |
| Over charge detection voltage(Cell) | 4.250V±0.025V |
| Over Discharge Detection Voltage(Cell) | 2.500V±0.025V |
| Over Current Discharge | 15.0A±0.2A |
| Over Current Charge | 15.0A±0.2A |
| Discharging Temperature | -20~65℃ Adjustable |
| Charge Temperature | -5~50℃ Adjustable |
| Max.Discharge Current | 10A |
| Dimension | |
| Length | 65± 0.3mm |
| Width | 32± 0.3mm |
| Height | 3.79± 0.3mm |
