4S 6A Protection Circuit Board with SMBUS Interface Suitable
4S 6A Protection Circuit Board with SMBUS Interface
Product Specifications
| Attribute | Value |
|---|---|
| Battery Type | Lithium ion |
| Over charge detection voltage (Cell) | 4.250V±0.025V |
| Over Discharge Detection Voltage (Cell) | 2.400V±0.025V |
| Compatible Interface | SMBUS |
| Over Current Discharge | 13.5A±0.2A |
| Over Current Charge | 5.5A±0.2A |
| Max Discharge Current | 10A |
| Dimension | 130*25*2.2 mm (L*W*H) |
| Operating Temperature | -25~60℃ |
Technical Details
| Model NO. | BAKTH-004S006A-0084-01 |
| Compliant certification standards | IEC62133 |
| Type of Protective Board | 4S lithium battery protection board |
Key Features
- Over-voltage/current protection (<0.1s response)
- Multi-battery compatibility
- Precision voltage detection with tight tolerances
- Robust protection for lithium battery packs
Applications
- Lithium ion Battery Packs
- Electric Tools
- Portable power solutions
- Battery management systems
4S 6A Protection Circuit Board with SMBUS Interface
Product Specifications
| Attribute | Value |
|---|---|
| Battery Type | Lithium ion |
| Over charge detection voltage (Cell) | 4.250V±0.025V |
| Over Discharge Detection Voltage (Cell) | 2.400V±0.025V |
| Compatible Interface | SMBUS |
| Over Current Discharge | 13.5A±0.2A |
| Over Current Charge | 5.5A±0.2A |
| Max Discharge Current | 10A |
| Dimension | 130*25*2.2 mm (L*W*H) |
| Operating Temperature | -25~60℃ |
Technical Details
| Model NO. | BAKTH-004S006A-0084-01 |
| Compliant certification standards | IEC62133 |
| Type of Protective Board | 4S lithium battery protection board |
Key Features
- Over-voltage/current protection (<0.1s response)
- Multi-battery compatibility
- Precision voltage detection with tight tolerances
- Robust protection for lithium battery packs
Applications
- Lithium ion Battery Packs
- Electric Tools
- Portable power solutions
- Battery management systems
Detailed Product Description
no data
